STR-DA6400ES
162
Pin No. Pin Name I/O Description
V26 PCI_AD07 I/O Two-way data bus with terminal Not used
W1 VSS - Ground terminal
W2 MM_DATA24 I/O Two-way data bus with the SD-RAM
W3 VSS - Ground terminal
W4 MM_DATA23 I/O Two-way data bus with the SD-RAM
W5 VCCM - Power supply terminal (+3.3V)
W22 VCCP - Power supply terminal (+3.3V)
W23 PCI_AD01 O
Address latch enable signal output to the parallel/serial converter, parallel bus/I2C bus con-
verter and fl ash rom
W24 to
W26
PCI_AD03 to
PCI_AD05
I/O Two-way data bus with terminal Not used
Y1 MM_DQS2 I/O Two-way data strobe signal with the SD-RAM
Y2 VCCM - Power supply terminal (+3.3V)
Y3, Y4
MM_DATA22,
MM_DATA21
I/O Two-way data bus with the SD-RAM
Y5 VCCM - Power supply terminal (+3.3V)
Y22 VCCP - Power supply terminal (+3.3V)
Y23 PCI_AD00 O
Command latch enable signal output to the parallel/serial converter, parallel bus/I2C bus
converter and fl ash rom
Y24, Y25 XIO_D12, XIO_D11 I/O Two-way data bus with terminal Not used
Y26 PCI_AD02 O Address data signal output to the parallel/serial converter and fl ash rom
AA1 to
AA3
MM_DATA25, MM_
DATA26, MM_DATA20
I/O Two-way data bus with the SD-RAM
AA4, AA5 VSS - Ground terminal
AA22 VSS - Ground terminal
AA23 LAN_COL I Collision detection signal input from the ethernet interface
AA24 XIO_AD O Data signal output terminal Not used
AA25,
AA26
XIO_D15, XIO_D14 I/O Two-way data bus with terminal Not used
AB1 to
AB4
MM_DATA27, MM_
DATA29, MM_DATA19,
MM_DATA18
I/O Two-way data bus with the SD-RAM
AB5, AB6 VSS - Ground terminal
AB7, AB8 VCCP - Power supply terminal (+3.3V)
AB9, AB10 VDD - Power supply terminal (+1.3V)
AB11,
AB12
VSS - Ground terminal
AB13,
AB14
VCCP - Power supply terminal (+3.3V)
AB15,
AB16
VDD - Power supply terminal (+1.3V)
AB17,
AB18
VSS - Ground terminal
AB19,
AB20
VCCP - Power supply terminal (+3.3V)
AB21,
AB22
VSS - Ground terminal
AB23 RESERVED I/O Not used
AB24,
AB25
XIO_SEL4, XIO_SEL1 O Chip select signal output terminal Not used
AB26 XIO_SEL0 O Chip select signal output to the fl ash rom
AC1 MM_DATA28 I/O Two-way data bus with the SD-RAM
AC2 VCCM - Power supply terminal (+3.3V)
AC3 MM_DATA17 I/O Two-way data bus with the SD-RAM
AC4 VCCM - Power supply terminal (+3.3V)
AC5 VDI_D33 - Not used
AC6 VDI_CLK2 - Not used
AC7 to
AC12
VDI_D07, VDI_D10,
VDI_D14, VDI_D16,
VDI_D17, VDI_D22
- Not used
