STR-DA6400ES
164
Pin No. Pin Name I/O Description
AF1 VSS - Ground terminal
AF2 VCCP - Power supply terminal (+3.3V)
AF3 to AF6
VDI_D01, VDI_D03,
VDI_D08, VDI_D13
- Not used
AF7 VDI_CLK1 - Not used
AF8 to
AF12
VDI_D19, VDI_D23,
VDI_D25, VDI_D28,
VDI_D30
- Not used
AF13 VDI_V1 - Not used
AF14 LAN_TX_CLK I Clock data signal input from the ethernet interface
AF15 LAN_TXD3 O Digital audio signal output to the ethernet interface
AF16 LAN_RX_CLK I Clock data signal input from the ethernet interface
AF17 LAN_RXD1 I Digital video and audio signal output to the ethernet interface
AF18 LAN_CLK O Clock data signal output to the ethernet interface
AF19 AO_SD0 O Digital audio signal output to the D/A converter (for network section)
AF20,
AF21
AO_SD2, AO_SD3 - Not used
AF22 SPDO - Not used
AF23 AI_OSCLK O Serial data transfer clock signal output to the A/D converter (for network section)
AF24 AI_SD1 I Serial data input terminal Not used
AF25,
AF26
BOOT_MODE04/
WDOG_OUT,
BOOT_MODE05
- Not used
