STR-DA6400ES
165
NETWORK BOARD IC8204 TL16C550DPT (PARALLEL/SERIAL CONVERTER)
Pin No. Pin Name I/O Description
1 NC - Not used
2 to 4 D5 to D7 I/O Two-way data bus with the connected media processor and parallel bus/I2C bus converter
5 RCLK I Reciever clock signal input terminal
6 NC - Not used
7 SIN I Serial data input terminal
8 SOUT O Serial data output terminal
9, 10 CS0, CS1 I Chip select signal input terminal
11 CS2_N I Chip select signal input from the connected media processor
12 BAUDOUT O Reciever clock signal output terminal
13 NC - Not used
14 XIN I System clock input terminal (3.6864MHz)
15 XOUT O System clock output terminal (3.6864MHz)
16 WR1 I Write enable signal input from the connected media processor
17 WR2 I Write enable signal input terminal Not used
18 Vss - Ground terminal
19 RD1 I Read enable signal input from the connected media processor
20 RD2 I Read enable signal input terminal Not used
21 NC - Not used
22, 23 DDIS, TXRDY O Not used
24 ADS I Address strobe signal input terminal Not used
25 NC - Not used
26 A2 I Address data signal input form the connected media processor
27 A1 I Address latch enable signal input form the connected media processor
28 A0 I Command latch enable signal input to the connected media processor
29 RXRDY O Not used
30 INTRPT O Interrupt request signal output to the connected media processor
31 to 34
OUT2, RTS, DTR,
OUT1
O Not used
35 MR (RESET) I Reset signal input terminal
36, 37 NC - Not used
38 CTS I Clear signal input terminal Not used
39 DSR I Data setting ready signal input terminal Not used
40 DCD I Data career detection signal input terminal Not used
41 RI I Modem status signal input terminal Not used
42 Vcc (3.3V) - Power supply terminal (+3.3V)
43 to 47 D0 to D4 I/O Two-way data bus with the connected media processor and parallel bus/I2C bus converter
48 NC - Not used
