Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA6400ES
236
C1290 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
< CONNECTOR >
CN1201 1-764-864-41 CONNECTOR, BOARD TO BOARD 12P
CN1202 1-573-829-11 CONNECTOR, BOARD TO BOARD 15P
CN1203 1-573-829-11 CONNECTOR, BOARD TO BOARD 15P
CN1204 1-766-719-41 CONNECTOR, BOARD TO BOARD 10P
CN1208 1-784-925-11 PIN, CONNECTOR 10P
CN1209 1-779-977-11 PIN, CONNECTOR 6P
< IC >
IC1202 8-759-710-97 IC NJM4565M-D
IC1203 6-709-814-01 IC CXD9725M-HFL
IC1212 8-759-710-97 IC NJM4565M-D
IC1213 6-709-814-01 IC CXD9725M-HFL
IC1222 8-759-710-97
IC NJM4565M-D
IC1223 6-709-814-01 IC CXD9725M-HFL
IC1232 8-759-710-97 IC NJM4565M-D
IC1233 6-709-814-01 IC CXD9725M-HFL
< RESISTOR >
R1202 1-216-049-11 METAL CHIP 1K 5% 1/10W
R1203 1-216-097-11 METAL CHIP 100K 5% 1/10W
R1204 1-216-025-11 METAL CHIP 100 5% 1/10W
R1205 1-216-013-00 METAL CHIP 33 5% 1/10W
R1206 1-216-013-00 METAL CHIP 33 5% 1/10W
R1207 1-216-097-11 METAL CHIP 100K 5% 1/10W
R1212 1-216-049-11 METAL CHIP 1K 5% 1/10W
R1213 1-216-097-11 METAL CHIP 100K 5% 1/10W
R1214 1-216-025-11 METAL CHIP 100 5% 1/10W
R1215 1-216-013-00 METAL CHIP 33 5% 1/10W
R1216 1-216-013-00 METAL CHIP 33 5% 1/10W
R1217 1-216-097-11 METAL CHIP 100K 5% 1/10W
R1222 1-216-049-11 METAL CHIP 1K 5% 1/10W
R1223 1-216-097-11 METAL CHIP 100K 5% 1/10W
R1224 1-216-025-11 METAL CHIP 100 5% 1/10W
R1225 1-216-013-00 METAL CHIP 33 5% 1/10W
R1226 1-216-013-00 METAL CHIP 33 5% 1/10W
R1227 1-216-097-11 METAL CHIP 100K 5% 1/10W
R1232 1-216-049-11 METAL CHIP 1K 5% 1/10W
R1233 1-216-097-11 METAL CHIP 100K 5% 1/10W
R1234 1-216-025-11 METAL CHIP 100 5% 1/10W
R1235 1-216-013-00 METAL CHIP 33 5% 1/10W
R1236 1-216-013-00 METAL CHIP 33 5% 1/10W
R1237 1-216-097-11 METAL CHIP 100K 5% 1/10W
R1252 1-216-049-11 METAL CHIP 1K 5% 1/10W
R1253 1-216-097-11 METAL CHIP 100K 5% 1/10W
R1257 1-216-097-11 METAL CHIP 100K 5% 1/10W
R1262 1-216-049-11 METAL CHIP 1K 5% 1/10W
R1263 1-216-097-11 METAL CHIP 100K 5% 1/10W
R1267 1-216-097-11 METAL CHIP 100K 5% 1/10W
R1272 1-216-049-11 METAL CHIP 1K 5% 1/10W
R1273 1-216-097-11 METAL CHIP 100K 5% 1/10W
R1277 1-216-097-11 METAL CHIP 100K 5% 1/10W
R1282 1-216-049-11 METAL CHIP 1K 5% 1/10W
R1283 1-216-097-11 METAL CHIP 100K 5% 1/10W
R1287 1-216-097-11 METAL CHIP 100K 5% 1/10W
************************************************************
A-1538-352-A F-HDMI BOARD, COMPLETE
**********************
< CAPACITOR >
C8300 1-128-994-21 ELECT CHIP 47uF 20% 10V
C8301 1-128-995-21 ELECT CHIP 100uF 20% 10V
C8302 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8303 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8304 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8305 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8306 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8307 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8308 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8309 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8310 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8311 1-128-994-21 ELECT CHIP 47uF 20% 10V
C8312 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8313 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8314 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C8315 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C8316 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C8317 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
* CN8300 1-821-205-11 CONNECTOR (RECEPTACLE, LVDS) 21P
* CN8301 1-821-188-11 HDMI CONNECTOR (HDMI IN 6)
< DIODE >
D8021 6-501-817-01 DIODE MA2J1110GLS0
D8022 6-501-817-01 DIODE MA2J1110GLS0
< TERMINAL >
ET8301 1-780-318-11 TERMINAL
ET8302 1-780-318-11 TERMINAL
< FERRITE BEAD >
FB8300 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC8300 8-753-278-35 IC CXB1443R-T4
IC8301 6-708-758-01 IC PCA9517DP.118
IC8302 6-702-302-01 IC TK11133CSCL-G
< RESISTOR >
R8302 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W
R8303 1-216-833-1
1 METAL CHIP 10K 5% 1/10W
R8304 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8305 1-218-990-81 SHORT CHIP 0
R8306 1-218-990-81 SHORT CHIP 0
R8307 1-218-990-81 SHORT CHIP 0
R8308 1-218-990-81 SHORT CHIP 0
R8309 1-218-990-81 SHORT CHIP 0
R8310 1-218-990-81 SHORT CHIP 0
R8311 1-218-990-81 SHORT CHIP 0
R8312 1-218-990-81 SHORT CHIP 0
R8313 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8314 1-216-841-11 METAL CHIP 47K 5% 1/10W
R8315 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8317 1-216-790-11 METAL CHIP 2.7 5% 1/10W
E-VOL F-HDMI
