Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA6400ES
237237
R8318 1-216-805-11 METAL CHIP 47 5% 1/10W
R8321 1-216-821-11 METAL CHIP 1K 5% 1/10W
R8322 1-216-821-11 METAL CHIP 1K 5% 1/10W
R8323 1-218-990-81 SHORT CHIP 0
R8324 1-218-990-81 SHORT CHIP 0
R8325 1-218-990-81 SHORT CHIP 0
R8326 1-218-990-81 SHORT CHIP 0
R8327 1-218-990-81 SHORT CHIP 0
************************************************************
FILTER BOARD
************
< CONNECTOR >
* CN1410 1-564-506-11 PLUG, CONNECTOR 3P
CN1422 1-785-101-11 PIN, CONNECTOR (3.96mm PITCH) 3P
< COIL >
L1411 1-457-594-11 COIL, LINE FILTER 10uH
L1412 1-456-594-11 COIL, CHOKE 33uH
L1420 1-457-594-11 COIL, LINE FILTER 10uH
************************************************************
HP BOARD
********
< CAPACITOR >
C201 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C202 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C203 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN201 1-784-922-11 PIN, CONNECTOR 5P
< JACK >
J201 1-815-313-11 JACK (PHONES)
< JUMPER RESISTOR >
R201 1-216-864-11 SHORT CHIP 0
R202 1-216-864-11 SHORT CHIP 0
R203 1-216-864-11 SHORT CHIP 0
************************************************************
KEY1 BOARD
**********
< CONNECTOR >
CN211 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
< RESISTOR >
R211 1-216-833-11 METAL CHIP 10K 5% 1/10W
R212 1-216-837-11 METAL CHIP 22K 5% 1/10W
< SWITCH >
S211 1-771-349-21 SWITCH, KEYBOARD (HDMI IN)
S212 1-771-349-21 SWITCH, KEYBOARD (HDMI OUT)
************************************************************
A-1538-294-A MAIN BOARD, COMPLETE
*********************
3-531-576-41 RIVET (DIA. 3), NYLON
4-117-852-01 INSULATED PLATE (MAIN-HS)
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C1491 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C1492 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C1493 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C1494 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C1495 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C1496 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1498 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2082 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C2083 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C2086 1-112-089-11 ELECT 47uF 20% 25V
C2087 1-112-089-11 ELECT 47uF 20% 25V
C2088 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2089 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2090 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2091 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2093 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2094 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2095 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2096 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2097 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2098 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2100 1-164-690-91 CERAMIC CHIP 0.0022uF 5% 50V
C2101 1-164-690-91 CERAMIC CHIP 0.0022uF 5% 50V
C2102 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C2103 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2189 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C2190 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C2191 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C2192 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2193 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2194 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C2195 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2196 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2197 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2198 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2200 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2201 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2202 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C2203 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C2204 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C2205 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C2206 1-128-198-11 ELECT 22uF 20% 63V
C2207 1-128-198-11 ELECT 22uF 20% 63V
C2208 1-128-198-11 ELECT 22uF 20% 63V
C2209 1-128-198-11 ELECT 22uF 20% 63V
C2210 1-128-198-11 ELECT 22uF 20% 63V
C2211 1-128-198-11 ELECT 22uF 20% 63V
C2212 1-128-198-11 ELECT 22uF 20% 63V
C2213 1-128-198-11 ELECT 22uF 20% 63V
C2214 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C2290 1-128-198-11 ELECT 22uF 20% 63V
C2300 1-128-198-11 ELECT 22uF 20% 63V
C2310 1-128-198-11 ELECT 22uF 20% 63V
