26 (GB) Connections
Connections
4 CONTROL S jacks
IN/PLUG IN POWER (5 V) jack (stereo minijack):
Connects to the CONTROL S OUT jack of other
Sony equipment. Also connects to the CONTROL
S OUT jack of the supplied remote control with the
supplied remote control cable (stereo cable) to be
used as a wired remote control. In this case, this
jack supplys 5 V to the remote control as power
source.
OUT jack (stereo minijack): Connects to the
CONTROL S IN jack of other Sony equipment.
Note
When using this jack, the remote control detector on the
projector does not function.
5 VIDEO IN/OUT connectors
VIDEO IN connector (BNC type): Connects to the
composite video output of the video equipment.
VIDEO OUT connector (BNC type): Connects to
the composite video input of a color monitor.
6 S VIDEO IN/OUT connectors
Y IN, C IN connectors (BNC type): Connects to the
Y and C video outputs of the video equipment.
S VIDEO IN/OUT connectors (4-pin, mini-DIN
type): Connects to the S video output or input
connector of the video equipment.
Note
The S VIDEO IN connector is disconnected when a cable
is connected to the Y/C IN connectors.
7 INPUT A connectors (BNC type)
R/C
R
/R-Y/P
R
, G/Y, B/C
B
/B-Y/P
B
, SYNC/HD, VD
connectors: Connect to the video equipment outputs.
According to the connected equipment, the RGB
(R, G, B), component (R-Y, G, B-Y) or HDTV (P
R
,
Y, P
B) signal is selected.
8 INPUT B connectors (BNC type)
R/C
R/R-Y/PR/VIDEO, G/Y Y/Y, B/CB/B-Y/PB/C,
SYNC/HD, VD connectors: Connect to the video
equipment outputs. According to the connected
equipment, the RGB (R, G, B), component (R-Y,
G, B-Y), HDTV (P
R, Y, PB), S VIDEO, VIDEO
signal is selected.
Front
9 AC IN socket
Connect the supplied AC power cord.
!º MAIN POWER switch
!¡ Front remote control detector
Location and Function of Connectors
