Sony VPH-D50HTU - Floor Installation Using Front Projection Flat Screen

Installation
Installation 9 (GB)
Floor Installation Using Front Projection Flat Screen
Be sure that the projector is level to the floor.
B: Difference in height between the projector’s bottom surface and the center of the screen
E: Horizontal distance between the center of the screen and the center of the green lens
F: Horizontal distance between the center of the screen and the standard hole for installation
Tolerances
B: ±5%
Other measurements: 0% to +5%
The distances in gray are the factory preset settings. Unit:mm (inches)
60 70 80 90 100 120 150 180 200 250
A (Vsize) 914 1067 1219 1372 1524 1829 2286 2743 3048 3810
(36) (42) (48) (54) (60) (72) (90) (108) (120) (150)
B (Hcent) 710 777 845 912 980 1114 1320 1526 1662 2005
(28) (30
5
/8) (33
3
/8) (36) (38
5
/8) (43
7
/8) (52) (60
1
/8) (65
1
/2) (79)
C (Width)
D (TD) 1956 2240 2529 2816 3102 3673 4551 5425 6012 7466
(77) (88
1
/4) (99
5
/8) (110
7
/8) (122
1
/4) (144
5
/8) (179
1
/4) (213
5
/8) (236
3
/4) (294)
E (Xlens) 1902 2179 2459 2738 3016 3571 4424 5274 5844 7257
(74
7
/8) (85
7
/8) (96
7
/8) (107
7
/8) (118
7
/8) (140
5
/8) (174
1
/4) (207
5
/8) (230
1
/8) (285
3
/4)
F (Lhole) 2033 2310 2591 2869 3148 3703 4556 5405 5976 7389
(80
1
/8) (91) (102) (113) (124) (145
7
/8) (179
3
/8) (212
7
/8) (235
3
/8) (291)
G (Lmax) 2535 2812 3092 3371 3649 4204 5057 5907 6477 7890
(99
7
/8) (110
3
/4) (121
3
/4) (132
3
/4) (143
3
/4) (165
5
/8) (199
1
/8) (232
5
/8) (255
1
/8) (310
3
/4)
H (Lfront) 1864 2141 2421 2700 2978 3533 4386 5236 5806 7219
(73
1
/2) (84
3
/8) (95
3
/8) (106
3
/8) (117
3
/8) (139
1
/8) (172
3
/4) (206
1
/4) (228
5
/8) (284
1
/4)
a) Sony VPS-80FH and VPS-100FH
b) Sony VPS-100FM
c) Sony VPS-120FH and VPS-120FM
Screen size
(inches)
28
a)
32
b)
32
c)
(1
1
/ 8 ) (1
5
/ 16 ) (1
5
/ 16 )
Wall
A
D
Floor
C
F
H
B
Center of the
green lens
Center of the screen
13.5˚
254 (10 )
Standard hole
for installation
E
G
Screen with 4:3 aspect ratio
