Sony VPH-D50HTU - Adjusting the Registration; Procedure

66 (GB) Adjustments
Adjusting the Registration
Adjustments
Procedure
1 Mark the center of the screen. (page 67 (GB))
v
2 Set the remote control to the service adjustment mode.
(page 35 (GB))
v
3 Select NO INPUT mode.
(page 67 (GB))
v
4 Select the internal oscillation pattern to be used for the registration
adjustment.
(page 67 (GB))
v
5 Reset the registration data to the factory preset levels. (Only if the
adjustment data has been modified before)
(page 99 (GB))
v
6 Adjust the green registration.
(pages 69 (GB) to 77 (GB))
1 CENT adjustment
2 SIZE and LIN adjustments
3 SKEW and BOW adjustments
4 KEY and PIN adjustments
5 KEY BALANCE and PIN BALANCE adjustments
v
7 Adjust the red registration.
(pages 78 (GB) to 86 (GB))
1 CENT adjustment
2 SIZE and LIN adjustments
3 SKEW and BOW adjustments
4 KEY and PIN adjustments
5 KEY BALANCE and PIN BALANCE adjustments
6 ZONE adjustment
v
8 Adjust the blue registration.
(page 87 (GB))
1 CENT adjustment
2 SIZE and LIN adjustments
3 SKEW and BOW adjustments
4 KEY and PIN adjustments
5 KEY BALANCE and PIN BALANCE adjustments
6 ZONE adjustment
v
9 Save the adjusted data as the standard data.
(page 88 (GB))
v
!º Adjust fine for each input signal.
(pages 89 (GB) to 95 (GB))
1 Adjustment of video input signal
2 Adjustment of RGB input signal
3 White balance adjustment
v
!¡ Activate the protection of the remote control.
(page 101 (GB))
v
!™ Adjust the picture.
(page 102 (GB))
v
Complete
Adjusting the Registration
