Installation
Installation 5 (GB)
Necessary Clearance for Installation and Maintenance
Make sure to provide enough room for maintenance service. Install the
projector, making reference to the dimensions below.
There should be a space of at least 30 cm (1
3
/16 inches) around the
ventilation holes. Never block the holes with any material.
Front
Installation Diagrams
Installation Diagrams
Unit: mm (inches)
Rear
Unit: mm (inches)
164.7 (6
15
/32)
345 (13
19
/
32
)
214 (8
7
/16)
603 (23
3
/4)
125 (4
29
/32)
Remote control detector
AC IN socket
MAIN POWER switch
302 (11
7
/8) (Ventilation holes)
133 (5
1
/4)
27
(1
1
/
16
)
35.5
(1
13
/
32
)
59.4
(2
11
/
32
)
125.8 (4
15
/
16
)
424 (16
11
/16) (Ventilation holes)
350 (13
25
/32)
110 (4
11
/
32
)
128 (5
1
/
32
)
Error code window/
Remote control detector
