Installation
4 (GB) Installation
Installation
Installation Procedures
By default, this projector is adjusted for 100-inch (4:3 aspect ratio) front
projection on the floor/desk. If you install the projector in other conditions,
you have to change some settings. Therefore, installation procedures
depend on the screen size or type, and installation method.
1 Verify the conditions of installation, such as angle of optical axis,
projection distance, height of the projector and screen.
.
2 Change the polarity according to the projection patterns. (page 20
(GB))
.
3 Install the projector and screen. (page 9 (GB))
.
4 Reset the registration data to factory setting. (page 100 (GB))
.
5 Adjust the CRT conversion angle. (page 23 (GB))
.
6 Adjust the lens focus and flapping of the lens. (page 60 (GB))
.
7 Adjust the registrations. (page 66 (GB))
.
8 Connect other equipment. (page 30 (GB))
.
9 Adjust each input signal. (pages 89 (GB) to 95 (GB))
• Fine adjustment for the registrations. (pages 89 (GB) and 92 (GB))
• Adjust the size or shift of the picture. (pages 90 (GB), 92 (GB) and
93 (GB))
• Adjust the blanking. (pages 91 (GB) and 93 (GB))
