Standard registration data and the input memory
If the adjusted registration data is saved as the standard data after installing
the projector, the registration data for all of the input memories will be
changed to reflect the new data in that installation condition. Therefore,
you can easily adjust the registration for each input signal.
For the procedure of how to save the standard data, see page 88 (GB).
Preset data at the factory
The projector presets seven types of basic data in memory numbers 00 to
06 of the factory data and service data blocks.
Memory number
00 15.7 kHz 60 Hz Video (NTSC3.58)
01 24.8 kHz 56 Hz RGB
02 31.5 kHz 60 Hz RGB
03 48.3 kHz 60 Hz RGB
04 64.0 kHz 60 Hz RGB
05 31.5 kHz 60 Hz IDTV (NTSC3.58)
06 33.8 kHz 60 Hz HDTV (Y/PB/PR)
Memory architecture
The following adjustment data will be saved in three memory blocks.
Memory Adjustment data Number of memories
Input memory
Color temperature
memory
Setting memory
Horizontal
frequency (fH)
Type of the
input signal
Vertical
frequency (fV)
Picture control (CONTRAST,
BRIGHT, COLOR, HUE,
SHARP)
SIZE/SHIFT
Blanking
Color temperature
Clamp position
V SHIFT
Registration
White balance
(BIAS/GAIN data for
each color temperature
of each screen)
Baud rate, CRT timer,
STATUS ON/OFF, language,
index, video memory, etc.
Memory numbers 00–49
(50 at maximum)
Four color temperature
settings (9300K/6500K/
5400K/3200K)
One for each projector
