A-4
Appendix A. Technical Information CRANEX Novus e
EARTH LEAKAGE CIRCUIT BREAKER (when required)
100 - 120 V~ Approved type, min. 16 A 250 V~
220 - 240 V~ Approved type, min. 10 A 250 V~,
breaker activation leakage current in accordance with local regulations.
Mechanical parameters
PANORAMIC
Source to Image layer Distance (SID) 500 mm (±10 mm)
Magnifi cation factor 1.25
Focus to skin distance, minimum 154 mm
WEIGHT
120 kg
DIMENSIONS
(H x W x D) 2316 x 865 x 1085 mm
VERTICAL HEIGHT OF CHIN REST
950 - 1750 mm (± 10 mm)
Digital image receptor (CCD)
PIXEL SIZE
96 microns
ACTIVE SENSOR SURFACE
147.5 x 6.1 mm
Timer
EXPOSURE TIMES
Adult 9.0 s
Child 8.0 s
Bitewing 2.3 + 2.3 s
TMJ 1.9 + 1.9 s
Sectional 1.9 - 9.0 s
Accuracy for the displayed exposure times ± 15%
SINGLE LOAD RATING
100 V~ 77 kV, 8 mA, 9 s, panoramic
120 V~ 77 kV, 10 mA, 9 s, panoramic
220-240 V~ 77 kV, 10 mA, 9 s, panoramic
BACK-UP TIMER
15 - 17 s (±15%)
Approved: Ukkonen Juha-Pekka 2015-03-13 13:08
Reviewed: Savinen Antti Juhani 2015-03-12 11:32
Approved
See PDM system to determine the status of this document. Printed out: 2016-01-27 12:19:26
D508980, 4
Copyright © 2015 by PaloDEx Group Oy. All rights reserved.
