A-3
CRANEX Novus e Appendix A. Technical Information
FILTRATION
Inherent fi ltration minimum 0.6 mm Al at 50 kV (IEC 60522/1999)
Additional fi ltration minimum 2 mm Al
Patient support attenuation equivalent less than 0.2 mm Al
Attenuation equivalent of plastic cover, approximately 0.25 mm Al
Total fi ltration minimum 2.6 mm Al at 77 kV
BEAM QUALITY
HVL over 2.77 mm Al at 73 kV
DAP (Dose Area Product) accuracy of displayed value better than 25%
PRIMARY PROTECTIVE SHIELDING
Minimum 0.5 mm Pb or equivalent
OUTER SHELL TEMPERATURE
+50ºC (122ºF) maximum
DUTY CYCLE
1:7, at maximum technique factors. (Example: an 77 kV, 10 mA, 9 s
exposure will have a 65 s cool-down period)
Power requirements
OPERATING LINE VOLTAGE
100 - 120 V~ or 220 - 240 V~, 50/60Hz
INPUT POWER
Standby: 26 W, maximum: 1100 W
MAXIMUM LINE IMPEDANCE
Apparent resistance of supply mains 0.5 ohm
MAXIMUM LINE FUSING
100 - 120 V~ 16A
220 - 240 V~ 10 A
MAIN FUSE
T-10A-H-250V
LINE SAFETY SWITCH (when required)
100 - 120 V~ Approved type, min. 16 A 250 V~
220 - 240 V~ Approved type, min. 10 A 250 V~
