A-5
CRANEX Novus e Appendix A. Technical Information
Leakage technique factors
PANORAMIC
100V~: 4564 mAs/h, exposure with maximum values
(77 kV, 8 mA, 9 s) according to the 1:5 duty cycle
120V~: 4713 mAs/h, exposure with maximum values
(77 kV, 10 mA, 9 s) according to the 1:7 duty cycle
220-240V~: 4713 mAs/h, exposure with maximum values
(77 kV, 10 mA, 9 s) according to the 1:7 duty cycle
Measurement bases
The kV is measured by monitoring differentially the current fl owing through 450
Mohm, 1% feedback resistor connected between the tube anode and ground.
The mA is measured by monitoring current in the HT return line, which equals the
tube current.
Collimator
TYPE
BLD-M-1
PRIMARY SLIT
Adult panoramic slit only. For child panoramic the exposure time is reduced
to give a reduced length image.
PRIMARY SLIT SIZE
0.7 - 0.75 x 38 mm
Z-motor
DUTY-CYCLE
Intermediate use: 6.25%, 25s ON, 400s OFF
Environmental data
OPERATING
Ambient temperature from +10ºC to +40ºC
Relative humidity 10 - 90%, no condensation
STORAGE/TRANSPORTATION
Ambient temperature from -20ºC to +50ºC
Relative humidity 5 - 85% no condensation
Atmospheric pressure 500 - 1080 mbar
Approved: Ukkonen Juha-Pekka 2015-03-13 13:08
Reviewed: Savinen Antti Juhani 2015-03-12 11:32
Approved
See PDM system to determine the status of this document. Printed out: 2016-01-27 12:19:26
D508980, 4
Copyright © 2015 by PaloDEx Group Oy. All rights reserved.
