Söring Arco-3000 - Arrangement of Modules of the Arco-1000 Table-Top

25/08/2004 © Söring Service-Manual Arco- and RF-units
1
not valid for A-3000/ -2000
2
not valid for Arco-2000
-16-
3
not valid for MBC600
4
not valid for Arco-1000
Arrangement of modules of the Arco-1000 Table-Top
mains transformer
mains filter
Ground- pin
rectifier
Patient electrode socket
mains switch
Gas- socket
single footswitch
Loudspeaker
mains board
(low power supply,
mains relays,
screening)
CPU
Handpiecerecognition
Output unit (assignment relays,
PE-monitoring, Bipo-recognition)
Coagulatormodule
High power supply
double footswitch
Loudspeaker Poti
gas connection
Synchro-socket
Frontpanel (modular design)
MG Mono
MAArgon
BI 600/2000
RF-Output Module
gassystem
Test resistor
