Söring Arco-3000 - Power Diagram Spray-Coagulation; Power Diagram Force-Coagulation -Effect 1

25/08/2004 © Söring Service-Manual Arco- and RF-units
1
not valid for A-3000/ -2000
2
not valid for Arco-2000
-78-
3
not valid for MBC600
4
not valid for Arco-1000
Power diagram Spray-Coagulation
0
20
40
60
80
100
120
100 200 300 400 500 1000 2000
Resistance in Ohm
Power in Watt
Spray 1
Spray 2
Spray 3
Spray 4
Spray 5
Power diagram Force-Coagulation -Effect 1
4
0
20
40
60
80
100
120
140
100 150 200 400 600 1000 2000
Resistance in Ohm
Power in Watt
Force 1 (Eff 1)
Force 2 (Eff 1)
Force 3 (Eff 1)
Force 4 (Eff 1)
Force 5 (Eff 1)
Leistungskurve= power diagram
