Söring Arco-3000 - Visual, Acoustical Signals, and Classification

25/08/2004 © Söring Service-Manual Arco- and RF-units
1
not valid for A-3000/ -2000
2
not valid for Arco-2000
-84-
3
not valid for MBC600
4
not valid for Arco-1000
13.1. Visual and acoustical signals
Activation RF on Visual signal Acoustical signal
Power on Green switch light
Cutting
4
X Yellow working-indicator Continuous tone 440 Hz
Coagulation
4
X Yellow working-indicator Continuous tone 480 Hz
Argon
1
X Yellow working-indicator Continuous tone 500 Hz
Bipolar Cutting
2,3,4
X Yellow working-indicator Continuous tone 550 Hz
Bipolar Coagulation
2,4
X Yellow working-indicator Continuous tone 550 Hz
PE- failure Red blinking signal Modulated warning-tone 370 Hz
Function error X Red signal
Output power error X Red signal
The level of the acoustical signal is adjustable between 45 and 65 dB(A).
The level of the warning-tone (Patient electrode failure) is fixed at 65 dB(A).
Classification
Safety class: I
Safety grade: according to EN60601-1 CF
Weight without trolley (Arco/RF): 24kg / 19kg
Dimensions (Arco/RF): WxHxD 430mm x 150mm x 560mm / 430 x 150 x 430
Applicable standards: EN60601-1, EN60601-2-2, VDE0750, VDE0107
