6.10 Signal shapes
,
Zeit
time
Spannung
voltage
This signal-shape is used for the function Cutting without Blend
Zeit
time
Spannung
voltage
T1
T2
Pulse-modulated RF-current, duty-cycle 3/8 = 37,5%
This signal-shape is used for the function Cutting with Blend
