Söring Arco-3000 - Arrangement of Modules of the MBC 601

25/08/2004 © Söring Service-Manual Arco- and RF-units
1
not valid for A-3000/ -2000
2
not valid for Arco-2000
-17-
3
not valid for MBC600
4
not valid for Arco-1000
Arrangement of modules of the MBC 601
mains transformer
mains filter
Ground- pin
rectifier
Patient electrode- socket
mains switch
Monopolar- socket1
Monopolar- socket 2
Bipolar- socket
single footswitch
loudspeaker
mains board
(low power supply,
mains relays,
screening)
CPU
Handpiece recognition
Output unit (assignment relays,
PE-monitoring, Bipo-recognition)
Cut module
Coagulator module
High power supply
double footswitch
Loudspeaker Poti
Frontpanel (modular design)
MG Mono
MG Mono
MG Mono
MA HF
BI Arco 3000 / M
RF output module
Test resistor
