Description of BMS-8N(V) stud welding devices
Operating Instructions Soyer Bolzenschweißtechnik 21
6.3.1 Support table stud diameter/charging voltage
Figure 3: Support table on the front panel
The charging voltage is fixed to the stud diameter and cannot be changed when
displaying the stud diameter.
For adjusting the charging voltage, switch to the display of the charging voltage.
See chapter “13.1 Adjusting the charging voltage on the stud welding device” on
page 47.
Item Designation
a Row of stud diameters in [mm].
b Row of the charging voltage assigned to the appropriate stud diame-
ter in [V].
70
Ø 3
100
Ø 4
115
Ø 5
140
Ø 6
175
Ø 7
190
Ø 8
000
a
b
