Description of the PS-1K stud welding gun
Operating Instructions Soyer Bolzenschweißtechnik 33
9.1 Technical data for the PS-1K stud welding gun
(*) With adapter plug, see technical data on the stud welding device.
Technical data for the PS-1K stud welding gun
Designation PS-1K stud welding gun (contact gun)
Item no. P02117
Welding procedure Capacitor discharge stud welding
Stud diameter M3 - M8
Stud chuck Adjustable
Stud length Adjustable stud chuck up to a maximum of 35 mm
Longer stud lengths with optional accessory possible
Stud welding devices The gun is approved for operation with the following
SOYER® stud welding devices:
• BMS-6 ISO
• BMS-8N
• BMS-8NV
• BMS-9 (*)
• BMS-9V (*)
• BMS-10N
• BMS-10NV
• BMS-10P
Weight approx. 0.4 kg without cable
Subject to technical changes
