Description of the PS-3K and PS-3K Stativ stud welding guns
36 Operating Instructions Soyer Bolzenschweißtechnik
The gun model with an adjustable support can take stud chucks of up to M10.
10.1 Technical data for the PS-3K (Stativ) stud welding gun
(*) With adapter plug, see technical data on the stud welding device.
i
The PS-3K and PS-3K Stativ stud welding guns may only be operated
with the stud welding devices specified in the technical data.
Technical data on the PS-3K (Stativ) stud welding gun
Designation Stud welding gun
PS-3K (contact gun)
PS-3K Stativ
Item no. PS-3K: P02131
PS-3K Stativ: P02143
Welding procedure Capacitor discharge stud welding
Stud diameter PS-3K: M3 - M8
PS-3K Stativ: M3 - M12
Stud chuck Adjustable
Stud length PS-3K: Adjustable stud chuck up to a maximum of
35 mm
Longer stud lengths with optional accessory possible
PS-3K Stativ: Stud length up to 60 mm, without
optional accessory.
Stud welding devices The gun is approved for operation on the following
SOYER® stud welding devices:
• BMS-6 ISO
• BMS-8N
• BMS-8NV
• BMS-9 (*)
• BMS-9V (*)
• BMS-10N
• BMS-10NV
• BMS-10P
Weight approx. 0.9 kg without cable
Subject to technical changes
