Soyer BMS-8NV - Technical Data for the PS-1 Stud Welding Gun

Description of the PS-1 stud welding gun
30 Operating Instructions Soyer Bolzenschweißtechnik
8.1 Technical data for the PS-1 stud welding gun
Technical data for the PS-1 stud welding gun
Designation PS-1 stud welding gun
Item no. P02110
Welding procedure Capacitor discharge stud welding
Stud diameter M3 - M8
Stud chuck Adjustable
Stud length Adjustable stud chuck up to a maximum of 35 mm
Longer stud lengths with optional accessory possible
Stud welding devices The gun is approved for operation on the following
SOYER® stud welding devices:
• BMS-6 ISO
• BMS-8N
• BMS-8NV
• BMS-10N
• BMS-10NV
• BMS-10P
Weight approx. 0.5 kg without cable
Subject to technical changes
