Description of BMS-8N(V) stud welding devices
22 Operating Instructions Soyer Bolzenschweißtechnik
6.3.2 Displaying the operating states
Figure 4: Operating states
Item Designation
a Ready
In normal operation, the LED lights up when the stud welding device
is ready for operation in normal mode.
b Stud on workpiece
The LED lights up when the earth terminal is connected and the stud
touches the workpiece.
c Release
The LED lights up when the trigger button on the welding gun is
pressed.
d Malfunction
The LED lights up when a malfunction of the stud welding device
occurs. See chapter “14.5 Malfunctions with an error message” on
page 54.
a
b
d
c
