12.2.3 Connecting the stud welding gun
Only use the welding guns approved by the manufacturer. See chapter “6.5 Per-
mitted stud welding guns” on page 24.
Plug the welding cable into the socket
(a) and turn the plug to the right up to
the stop.
Plug the control cable into the control
cable socket (b).
