Description of the stud chuck
40 Operating Instructions Soyer Bolzenschweißtechnik
Step 4: Undo the union nut.
Step 5: If there is still a stud chuck in the gun, remove it.
Step 6: Slide the stud chuck up to the stop
into the spring piston of the gun.
Step 7: Hand-tighten the union nut.
Step 8: Plug the support tube onto the gun.
Installing the stud chuck (gun without support).
