ER 200 - ER 220
ER150 - ER160 - ER165
Code M0076 - rev.1.6
(04/2005)
SPACE s.r.l. – 10090 Trana (TO) Via Sangano, 48 Page 5/ 40
Tel. (+39) 011/ 933.88.65 – Fax (+39) 011/ 933.88.64
e-mail: info@spacetest.com
Caution: Never lift the machine by
means of the shaft
Shock hazard
Wear work gloves
Wear work shoes
Wear safety goggles
3 COMPOSITION OF EQUIPMENT
3.1 Models ER200 - ER220
PEDAL BRAKE
(MOD. ER200 ONLY)
DISPLAY SCREEN
INTEGRATED IN THE
WEIGHT HOLDER
SHAFT
ROD WITH RULE FOR MEASURING
THE DISTANCE OF THE INSIDE FLANK
OF THE RIM.
(IN INITIAL POSITION)
WEIGHT HOLDER
SMALL, MEDIUM
AND LARGE CONE
WEIGHT PLIERS
GAUGE FOR MEASURING
RIM WIDTH
CALIBRATION
WEIGHT (100g)
MASTER SWITCH (ON REAR
OF WHEEL BALANCER)
LOCKNUT
LEVER FOR QUICK
ENGAGEMENT/DISENGAGEMENT
MOD.ER220 ONLY
PRESSURE
RING
PROTECTION
CAP
