INSTRUCTION MANUAL
SPACE s.r.l.
ER 200 - ER 220
ER150 - ER160 - ER165
Code M0076 - rev.1.6
(04/2005)
SPACE s.r.l. – 10090 Trana (TO) Via Sangano, 48 Page 39/ 40
Tel. (+39) 011/ 933.88.65 – Fax (+39) 011/ 933.88.64
e-mail: info@spacetest.com
13 ERROR SIGNALS
During wheel balancer operation, if wrong commands are given by the operator or device
faults occur, an error code or symbol may appear on the display screen. Press key
F1/
to return to the previous program phase after remedying the fault. Below is a
troubleshooting chart.
ERROR CODE CAUSE
2 No rotation signal
May be due to faulty position transducer or transducer not fitted
correctly. Or else the motor is faulty or has not started because
something is preventing its rotation.
3 Excessive weight value in wheel
balancer calibration
During the calibration procedure, the machine detects excessive
weight. The weight may not have been fitted properly; the data
acquisition or measurement sensor may be faulty.
8 Insufficient weight value in wheel
balancer calibration
During the calibration procedure, the machine detects insufficient
weight. The weight may not have been fitted properly; the data
acquisition or measurement sensor may be faulty.
9 Calibration spin not completed
During the calibration procedure, the spin is not completed because
the (STOP) key has been pressed.
14 MAINTENANCE
IMPORTANT!:
Before doing any maintenance job, the machine will have to be
disconnected from the power mains.
To clean plastic panels or surfaces use alcohol (AVOID USING LIQUIDS CONTAINING
SOLVENTS).
The DISPLAY SCREEN must be cleaned with a dry cloth; if it is very dirty, clean with a damp
cloth and then dry.
Do not spray the alcohol directly on the control panel and do not clean using strong jets of
compressed air.
Do not use pneumatic or power tools in damp or slippery environments and do not leave
these exposed to the elements.
15 STORAGE AND SCRAPPING
Storage -
If the machine has to be stored for a long period of time, disconnect all supply lines
and protect the display screen, which could be damaged by excessive dust.
Grease any parts liable to be damaged by dryness.
Scrapping -
If the machine is to be no longer used, it must be made inoperative:
All those parts that could represent a potential hazard risk must be correctly disposed of.
Dispose of parts according to category.
Scrap as iron scrap through authorised channels.
Parts considered as special waste must be removed and split up according to type and then
disposed of through authorised channels according to applicable regulations.
