Spectra Engineering MX800 - 7.2 MX800 Specifications; Operating Frequency Bands

MX800 Transceiver Technical Manual
© SPECTRA ENGINEERING 2006 Revision 4.2.3
104
7.2 MX800 Specifications
Minimum performance to exceed the following for 30 MHz to 960 MHz*:
AS4295-1995
ETS 300 086 Jan 1991,ETS 300 113
FCC Part 90
TIA/EIA-603
BAPT 225 ZV 1/2098 (German Soft keying)
CEPT T/R 24-01 E Sept 1988
EC Marking, EC EMC Directive 89/336/EEC
RFS25, RFS26, RFS32
*Conforms but may not be approved.
Consult Spectra Engineering regarding current type approvals and for latest
and current MX800 Specification Data sheet.
7.2.1 Operating Frequency Bands
The MX800 is available in a number of models, which cover the range of
operating frequency bands. As the transmitters and receivers are functionally
independent the radios may be cross-banded if required. Refer to section 7.4
for details of the band breakdown.
