MX800 Transceiver Technical Manual
© SPECTRA ENGINEERING 2006 Revision 4.2.3
112
Notes:
1. Band E, L2, R3, Q2 receive only
2. Band E2, R2, V2 transmit only
3.
0
Indicates preferred band
4. Band A2, A3: 4 MHz Rx VCO Sw BW
7.4 MX800 Model Number Configuration Guide
The MX800 build can be specified by the model number. The diagram below
shows how the model number is derived from the wanted options. Consult
Spectra for availability details on specific configurations and options.
Due to ongoing development please refer to www.spectraeng.com.au for the latest revision of this document
page.
Band
Frequency
A2 30-39 MHz
A3 39-50 MHz
A 66-80 MHz
B° 70-88 MHz
C 135-160 MHz
D 155-180 MHz
D3° 148-174 MHz
E 177-207 MHz
E2 177-185 MHz
F 195-225 MHz
G 220-250 MHz
H 245-275 MHz
I 270-300 MHz
J 295-325 MHz
K 320-350 MHz
L 345-375 MHz
M 370-400 MHz
N 395-430 MHz
N2° 400-435 MHz
O 425-460 MHz
O2 435-470 MHz
P 455-490 MHz
P2° 450-485 MHz
P3 475-495MHz
Q° 485-520 MHz
Q2 500-532 MHz
Q3 485-505 MHz
Band
Frequency
R 805-825 MHz
R2 746-764 MHz
R3 776-794 MHz
S 824-849 MHz
T 850-870 MHz
U 872-905 MHz
V 890-915 MHz
V2 900-925 MHz
W 917-950 MHz
X 925-960 MHz
Z None
Front Panel
S Standard
C Custom
RF Config
D Duplex
S Simplex
MX800
Controller Options
Z Standard Controller
L LC Controller
Frequency Stability
1 1.0 ppm (-30 to 60°C)
2° 1.5 ppm (-10 to 60°C) &
2.5 ppm (-30 to -10°C)
4 20 ppm (-30 to 60°C)
5 2.5 ppm (-10 to 60°C) &
5 ppm (-30 to -10°C)
Options
Z No options
S Options fitted
(Specify separately)
Channel Allocation
N 12.5 kHz (Narrow)
M 20 kHz (Medium)
W 25 kHz (Wide)
D 30 kHz (Data)
C 50 kHz (Cellular)
P 12.5/25 kHz
Programmable
Tx Power
E 1 Watt (Extra Low, Bands N - Q)
L 5 Watt (Low, N - Q3)
N 15 Watt (800 MHz Normal)
I 25 Watt (Intermediate)
M 35 Watt (800 MHz Medium)
H 50 Watt (High)
Z None
Rx Freq
Tx Freq
