3.17.1 Installation
CAUTION: COMPONENTS USED ARE STATIC DAMAGE SENSITIVE!
Components Required:
1. T26/19 Option PCB & RJ45 Daughter PCB. Qty-1
2. M3X 25mm Standoff posts. Qty-4
3. M3X 3mm screws Qty-3
4. CABLE IDC SKT - IDC SKT 16W 125mm cable Assy. Qty-1
5. CABLE IDC SKT-IDC SKT 10WAY 150mm cable Assy. Qty-1
6. CABLE IDC SKT-IDC SKT 16WAY 170mm cable Assy. Qty-1
7. CABLE IDC SKT-IDC SKT 10W 330mm cable Assy. Qty-1
8. CABLE IDC DB9M-IDC SKT 10W 195mm cable Assy. Qty-1
9. CABLE IDC DB15F-IDC SKT 16W 210mm cable Assy. Qty-1
10. CABLE IDC SKT-IDC SKT 16WAY 210mm cable Assy. Qty1
Test Equipment Required:
1. Communications Test Set
2. MX800 Radio Interface Box
Note# When installing cables insure that they are fitted with the correct
orientation.
Method:
1. Remove the cover to the MX800 radio.
2. Remove mother board from chassis of radio. Note cable connection and
orientation.
3. Install the CABLE IDC SKT-IDC SKT 10W 330mm cable Assy
between connector SKI on the Motherboard (going under nether mother
board) and SKU/B on the Option board, taking note that the cable is
correctly orientated. This cable lays under the mother board. Issue cable
is not crushed when refitting mother board.
