Spectra Engineering MX800 - T19;26 Option Board Features; Status Tone Encoding And Decoding (T19 only); Five Tone Encoded; Decoder (T19 only); DTMF Decoder

MX800 Transceiver Technical Manual
© SPECTRA ENGINEERING 2006 Revision 4.2.3
48
Figure 3-10 MX800 T19/T26Option Board
Due to ongoing development please refer to www.spectraeng.com.au for the latest information
regarding this option.
Note These are software selectable provided the correct option board is
selected/used, and not all option can be used in conjunction with each
other. Some parts many not be populated.
Jumpers referred below are those on this option PCB.
