Technical Manual Technical Description
© SPECTRA ENGINEERING 2006 Revision 4.2.3
65
3.20 T34 Ethernet option
The T34 Ethernet Option is a small circuit board that is installed inside the
MX800 transceiver to allow diagnostic data from the MX800 to be sent over
a UTP Ethernet link.
The T34 includes a web server to output web pages for analysing the health
of the host MX800 using a standard HTML web browser.
The T34 board intercepts the serial data port of the MX800 and converts the
MX800 data to and from IP packets that are transferred over the Ethernet
link.
When using the Mxtools software, the T34 board sends and receives data to
the MX800 motherboard normally as long as communication via the Ethernet
connection with the MX800 is inactive.
A technical manual is available for this option please contact
sales@specteng.com.au for a copy of this manual.
