Take care if too much offset is used as this may effect the modulation
symmetry. The use of this feature and a low frequency carrier dithering has
proven to eliminate the previous requirements of extremely high stability
reference frequency inputs.
The MX800 has been widely installed for the use in simulcast systems. These
DSP based systems provide automatic compensation for changes in
modulation delay characteristics.
Drawing No.
Description
SC001-1A MX800 Conventional Systems Examples
SC001-2A MX800 Conventional Systems Examples
SC003-1A MX800 T19/T26 option Board Example
SC004-1A MX800 Paging Configuration Example
SC006-1A MX800 Link System Configuration Example
