Spectra Engineering MX800 - INTERNAL POWER CABLE ASSEMBLY; Internal Power Cable Diagram

24/01/98 1-8-96
DATE
BY
APP
REF DWGS DRAWN CHECKED APPROVED DESIGNED
F.H. G.J.
SHEET
CABLE ASSEMBLY INTERNAL POWER
TITLE DRAWING No
SPECTRA
9 TRADE ROAD TEL (+618) 92482755
WESTERN AUSTRALIA
ENGINEERING
FAX (+618) 92482756
MALAGA 6090
(C) COPYRIGHT 1991-97
EV0004.DWG
REV
OF
1
1
A
DATE
REVISION
RED
LENGTH 250 ±5mm
2 x 26/0.32 PVC INSUL. WIRE
M3 FARNELL SOLDER LUG 101-481 OR EQUIV.
REAR VIEW
RED - PIN 3
PLT-253R SOCKET
FIGURE 8
BLACK WIRE 7/0.16 PVC INSUL.
RED WITH BLACK STRIPE - PIN 2
RED - PIN 3
NC - PIN 1
LENGTH - 20mm RUBBER SLEEVING
LENGTH 60 ±5mm
BLACK
MSTB2.5/3-ST-5.08
PHOENIX 3 WAY SOCKET
RED WITH BLACK STRIPE
BLACK
RED
POLARIZED SOCKET
TWISTED PAIR 7/0.16 PVC INSUL. WIRE
RED
LENGTH 100 ±5mm
0.1" PITCH SIL
