Quick Barcode Connector Application
If you are using Spectralink 8450/8452 handsets, the Spectralink Quick Barcode Connector™
(QBC) application enables you to capture and decode barcode patterns with the handset and
transfer the data to applications running on one or more host computers. Data can be
transferred in single endpoint mode (one host computer) or multiple endpoint mode (many host
computers). Please refer to the Quick Barcode Connector Administration Guide for complete
information.
Registrations
Each registration can optionally be associated with a private array of servers for completely
segregated signaling. The Spectralink handsets support six registrations.
In the following tables, x is the registration number which can be from 1-6.
Table 8-49: Registration Parameters
Parameter
Permitted Values
Default
reg.x.acd-login-logout
reg.x.acd-agent-available
0 or 1
0 or 1
0
0
If both ACD login/logout and agent available are set to 1 for registration x, the ACD feature will be enabled for that
registration.
reg.x.address
string address
Null
The user part (for example, 1002) or the user and the host part (for example, 1002@Spectralink.com) of the
registration SIP URI.
reg.x.applyServerDigitMapLocally
0 or 1
0
If 1 and reg.x.server.y.specialInterop is set to lync2010, lync2013 or Skype for Business, the
handset uses the dialplan from the Microsoft Lync Server. Any dialed number will apply the dial plan locally.
If 0, the dialplan from the Microsoft Lync Server is not used.
reg.x.auth.domain
string
Null
The domain of the authorization server that is used to check the user names and passwords.
reg.x.auth.password
string
Null
The password to be used for authentication challenges for this registration. If the password is non-Null, it will
overrule the password entered into the Authentication submenu on the Settings menu of the handset.
reg.x.auth.userId
string
Null
User ID to be used for authentication challenges for this registration. If the User ID is non-Null, it will overrule the
user parameter entered into the Authentication submenu on the Settings menu of the handset.
reg.x.csta
0 or 1
0
If 0, the uaCSTA (User Agent Computer Supported Telecommunications Applications) feature is disabled. If 1,
uaCSTA is enabled (overrules the global parameter voIpProt.SIP.csta).
reg.x.dialPlanName
String
Null
If reg.x.server.y.specialInterop is set to lync2010, lync2013 or Skype for Business, the
dialplan name from the Microsoft Lync Server is stored here. Each registration has its own name for this dialplan.
Note: Do not change this parameter if set by Microsoft Lync.
