Tip: Choosing a Provisioning Protocol
By default, Spectralink sets FTP as the provisioning protocol on all Spectralink
handsets. This guide focuses on the FTP provisioning protocol. Other supported
protocols include FTPS, TFTP, HTTP, and HTTPS.
See the Spectralink 84-Series Wireless Telephone Deployment Guide for a full
explanation of setting up FTP directories for both initial and central provisioning.
To set up an FTP server using FileZilla Server:
1 Download and install the latest version of FileZilla Server.
2 After installation, a Connect to Server pop-up displays on your computer. Select OK to
open the administrative user interface.
3 To configure a user, select Edit> Users in the status bar.
4 Select Add.
5 Enter the user name for the handset and select OK.
For example, bill123.
6 Select the Password checkbox and enter a password.
For example, 1234. The handset will use this password to log in.
Settings: FTP username and password
When you set up the initial provisioning server as an FTP server, use
administrator for the username and admin123 for the password. Ensure all
checkboxes are checked.
7 Select Page> Shared folders to specify the server-side directory where the provisioning
files will be located (and the log files uploaded).
8 Select Add and pick the directory.
9 To allow the handset to upload logs onto the provisioning server, select the Shared
Folders> Files> select Write and Delete checkboxes, and then select OK.
10 Determine the IP address of the FTP server by entering cmd in the Run dialog on your
Start menu, and ipconfig in the command prompt.
IP addresses of your network cards are displayed. One of them (if there are more than
one) will be your FTP server.
