SPECTRO xSORT - 4 Technical Data

Technical data
SPECTRO xSORT
— 05.09.2014 —
33
4 Technical data
Name Value
Operating voltage range 9.0 – 12.6 V
X-ray tube Rh (opt. W) anode, up to 50 kV, up to 125 µA,
max. 2.5 W
Total power during the analysis 11 W
Total power in the standby mode 6 W
Storage conditions -20 – +50°C; -5 – 120°F
Temperature range during start-up +5 – +40 °C; 41 – 104 °F
Operating range
(permissible ambient temperature)
-10 – +45 °C; 14 – 113 °F
Air humidity max. 80%
Protection class IP 52
Standards DIN EN 61010-1,
Charger:
Name Value
Operating voltage range 100-240 V 50/60 Hz +/- 10 %
Output 30 W
Storage conditions -20 – +50 °C; -5 – 120 °F
Temperature range 0 – 40°C; 32 – 104°F
Air humidity max. 80%
Protection class IP 20
Standards DIN EN 60335-1 / DIN EN 60335-2-29
