Spare part Name/items supplied No.
Rubber boot holder, complete
with seal
1x V048R2D rubber boot holder complete with seal, escutcheon S3
5x self-tapping screw
5x W1451 M4x16 TX20 steel 10.9 galvanized (A3K) pan head screw with ange
and hexalobular socket for thermoplastic materials
54088
Clip
for 2 contact elements for VCS0
5x clip for the connection of two CS0 double contact elements
53534
Clip
for 3 contact elements for VCS0
5x clip for 3 contact elements
53536
Cross gate
37° for VCS0
1x cross gate 37°
51897
Coupling for potentiometer Bxx
(PL310) for VCS0 joystick
1x CS071 F potentiometer clip for CS0 potentiometers Bxx, PQxx, PDxx, PBxx
1x coupling plate
2x NS045-39 A clamping lug for encoder
1x ZR.01.014.004 gearwheel M=1 Z=14 Ø=3.2 date: 28.01.2016
1x grub screw
4x locking washer S4
2x at head screw with hexalobular socket 1x ISO 7045 M3x6 steel 4.8 galvanized
ws pan head screw with cross head H
1x toothed segment for potentiometer drive
1x potentiometer cam shaft 1x at head screw 1x at head screw 2x ISO 4017
M4x6 steel 8.8 galvanized A2K hex head screw with thread to the
head
53537
