91
Spohn + Burkhardt
A.3. Joystick VCS0 96…
Version with
• Standard knob G41
• Rubber boot V041N
• Escutcheon V048K3
• Escutcheon holder V048R1
Figure 23.
67
Ø 81
4,5
67
96
Joystick VCS0 96… – dimension drawing (dimensions in mm)
