A.4. Joystick VCS0 72…
Version with
• Standard knob G41
• Rubber boot V040KE2
• Escutcheon V0044
• Escutcheon holder V028R
Figure 24.
72
67
Ø 81
4,5
67
Joystick VCS0 72…with standard knob G41 – dimension drawing (dimensions in mm)
