93
Spohn + Burkhardt
A.5. Joystick VCS0 SO…
Version with
• Standard knob G41
• Rubber boot V040KE2
• Boot holder CS092 V0044
• Hose clip ZY72x5
Figure 25.
42
Ø 50
4,5
42
Joystick VCS0 SO… with standard knob G41 – dimension drawing (dimensions in mm)
