UM2469 Rev 1 35/59
UM2469 STM32F7308-DK Discovery board I/O assignment
58
H14 PG8 GPIO_Output USB_OTGFS_PPWR_EN
H15 PC6 USART6_TX -
J2 PF3 FMC_A3 -
J3 PF4 FMC_A4 -
J4 PH5 I2C2_SDA ARD_D14_STMOD+_I2C2_SDA
(1)
K1 PF7 UART7_TX PMOD_UART7_TXD
K2 PF6 UART7_RX PMOD_UART7_RXD
K3 PF5 FMC_A5 -
K12 PH12 GPIO_Output USB_OTGHS_PPWR_EN
K13 PG5 FMC_A15 -
K14 PG4 FMC_A14 -
K15 PG3 FMC_A13 -
L1 PF10 ADC3_IN8 ARD_A3_ADC3_IN8
L2 PF9 UART7_CTS PMOD_UART7_CTS
L3 PF8 UART7_RTS PMOD_UART7_RTS
L12 PH11 TIM5_CH2 -
L13 PH10 GPIO_Input USB_OTGHS_OVCR_INT
L14 PD15 FMC_D1 -
L15 PG2 FMC_A12 -
M2 PC0 ADC2_IN10 -
M3 PC1 ADC2_IN11 -
M4 PC2 SPI2_MISO STMOD+_SPI2_MISOs
M5 PC3 SPI2_MOSI STMOD+_SPI2_MOSIs
M6 PB2 QUADSPI_CLK -
M7 PG1 FMC_A11 -
M11 PH6 TIM12_CH1 ARD_D9_TIM12_CH1
M12 PH8 I2C3_SDA -
M13 PH9 GPIO_Output CTP_RST
M14 PD14 FMC_D0 -
M15 PD13 QUADSPI_BK1_IO3 -
N2 PA1 TIM2_CH2 ARD_D10_TIM2_CH2_SPI1_NSS
N3 PA0-WKUP SYS_WKUP1 -
N4 PA4 ADC2_IN4 ARD_A1_STMOD+_ADC_DAC
(2)
N5 PC4 ADC2_IN14 ARD_A2_ADC
Table 17. I/O assignment (continued)
Pin
number
Pin Function Label
