STM32F7308-DK Discovery board I/O assignment UM2469
36/59 UM2469 Rev 1
N6 PF13 FMC_A7 -
N7 PG0 FMC_A10 -
N11 PE13 FMC_D10 -
N12 PH7 GPIO_Output LCD_RST
N13 PD12 FMC_A17 -
N14 PD11 FMC_A16 -
N15 PD10 FMC_D15 -
P2 PA2 USART2_TX ARD_D1_USART2_TX
P3 PA6 ADC2_IN6 -
P4 PA5 SPI1_SCK ARD_D13_SPI1_SCK
P5 PC5 GPIO_Output ARD_D2_GPIO
P6 PF12 FMC_A6 -
P7 PF15 FMC_A9 -
P8 PE8 FMC_D5 -
P9 PE9 FMC_D6 -
P10 PE11 FMC_D8 -
P11 PE14 FMC_D11 -
P12 PB12 GPIO_Output USB_OTG_HS_ID
P13 PB13 GPIO_EXTI13 USB_OTG_HS_VBUS
P14 PD9 FMC_D14 -
P15 PD8 FMC_D13 -
R2 PA3 USART2_RX ARD_D0_USART2_RX
R3 PA7 GPIO_Output SYS_LD_USER1
R4 PB1 GPIO_Output SYS_LD_USER2
R5 PB0 TIM3_CH3 ARD_D5_STMOD+_TIM3_CH3
(2)
R6 PF11 GPIO_Input PMOD_RESET
R7 PF14 FMC_A8 -
R8 PE7 FMC_D4 -
R9 PE10 FMC_D7 -
R10 PE12 FMC_D9 -
R11 PE15 FMC_D12 -
R12 PB10 GPIO_EXTI10 USB_OTGFS_OVCR_INT
R13 PB11 GPIO_EXTI11 PMOD_INT
Table 17. I/O assignment (continued)
Pin
number
Pin Function Label
To Next Page
