Error! Main Document Only.Chapter 5. Installing the Display System STACK ST8100 Display System
26 Users Guide
Ignition System Normally Fitted To Connection Point
Bosch Citroen AX 'Sport' and
'GT'
Tacho output (coil negative) with
100K series resistor
Bosch 3-pin CD Porsche 911 Carrera
'76
Pin 'C' (points connection)
Bosch 8-pin CD Porsche 930 Turbo '76 Pin 7 on ignition unit
'Contactless' Accessory only Dedicated tacho output
Cosworth ECU DFR89 ECU connector pin 'N'
Electromotive (Wasted
spark system)
Accessory only Tacho o/p with 33K series resistor
General Motors
GME-071
Formula Vauxhall
Lotus
Tacho output (coil negative) with
10K series resistor
Lucas CD racing
(Sparkbox)
F3000 Connector 'C' pin (7 pin)
Lumenition
Performance (Black)
Blue wire from distributor pick-up
Lumenition Optronic
MK17 (Silver)
Accessory only Brown wire on coil negative
Motoplat flywheel
system
Use the optional ST696 Engine
Speed sensor with this type of
ignition system
Motorcraft Formula Ford Coil negative with 47K series
resistor
Sodamo engine
management
Formula Renault White wire on coil negative
Zytek ECU Accessory only Dedicated tacho output
Bosch Blue Coil (With
points or Transistor
Assisted Ignitions)
Ignition upgrade for
Formula Fords 1600 &
2000 Etc.
Coil negative with 47K series
resistor (Note fit resistor close to
coil with suppressed Ignition leads)
