Helios Users Guide
www.starcomgpsglobal.com 131
For example, if the reading in the car shows 10 and the reading in the unit
shows 11, calculate as follows:
10 ÷ 11 = 0.90
In this case you will enter 90% in the Fixing Factor field.
If the reading in the car shows 10 and the reading in the unit shows 9,
calculate as follows:
10 ÷ 9 = 1.11
In this case you will enter 111% in the Fixing Factor field.
Click Send to send the new parameters to the unit.
Odometer
Installation
Connect the odometer pulse to the Odometer WHITE/BLACK cable on 24-pin
Helios wire harness (Pin 20).
Initial settings
Connect the Helios unit to the computer. In Installer application, go to Helios
parameters > General and change the settings as follows:
Mileage: 0
Fixing Factor (%): 100
Mileage from: Odometer
Current Value: 0
Pulses Per KM: 1
