Start Shaphon CC-M3 User Manual

4
Pause
Connect external pause key
17
Start
Connect external start key
5
Z + limit
Connect Z axis + limit switch
18
Z - limit
Connect Z axis – limit switch
6
Close
Connect external general switch
19
Torch collision
Connect the lifter collision check switch
7
X 0 point
X 0 mechanical origin
20
Y 0 pint
Y 0 mechanical origin
8
Torch A in position
Connect torch A in-position switch
21
Torch B in position
Connect torch B in-position switch
12
24V +
External DC24V+
24
24V +
External DC24V+
13
24V -
External DC24V ground
25
24V -
External DC24V ground
When choose “Use Outside Input” in Ctrl menu, the input definitions are partly different.
25-pin port
Signal definition
Instruction
1
X + limit
Connect X axis + limit switch
14
X - limit
Connect X axis – limit switch
2
Y + limit
Connect Y axis + limit switch
15
Y - limit
Connect Y axis – limit switch
3
Arc strike success signal
Connect plasma power arc strike success signal
16
Emergency stop
Connect external emergency-stop key
4
Pause
Connect external pause key
17
Start
Connect external start key
5
Manual direction X+
Connect X+ switch
18
Manual direction X-
Connect X- switch
6
Manual direction Y+
Connect Y+ switch
19
Manual direction Y-
Connect the Y- switch
7
Speed up
Connect speed up switch
20
Speed down
Connect speed down switch
8
Torch up
Connect torch up switch
21
Torch down
Connect torch down switch
12
24V +
External DC24V+
24
24V +
External DC24V+
13
24V -
External DC24V ground
25
24V -
External DC24V ground
Output signal port definition
Diagnosis interface can check input port, and change the position of the input port and set the input signal
logic.
25-pin port
Signal definition
Instruction
1
M10
Gas/preheat
14
M12
Cutting oxygen/arc strike
2
M14
Torch A up
15
M16
Torch A down
3
M18
Low preheat
16
M20
Ignition
