Start Shaphon CC-M3 - Mach (Machine) Parameters

Figu (Figure) parameters
1
Pretreat Figure
You’d better not choose figure pretreatment for oversized file
2
Kerf Display
Cancel kerf line display to simplify figure display
3
Outline Display
Cancel outline display to simplify figure display
4
Pierce No. Display
Cancel pierce number display to simplify figure display
Figure pretreatment: set whether preview figure before cut, when file is over 1M, can choose don’t pretreat
figure to save time
Note: no effect on cutting path display
Mach (Machine) parameters
1
External Limit Valid
1 use, 0 don’t use
2
Soft Limit Valid
1 valid, 0 invalid
3
Torch Collision
1 use, 0 don’t use
4
Dual Side XZ/YZ
1 YZ axis, 0 XZ axis
