Start Shaphon CC-M3 User Manual

F5 Reverse, change output port level high/low.
Adjust moving precision
Start ---> parameter-system (numerator:2, denominator: 1) ---> manual-point move-increment:100 --->
move-direction buttons-measure actual moving distance ---> parameter-system-calculation-input actual
distance-press Enter, numerator & denominator change-save parameters ---> manual-point move verification
---> right or not ---> yes ---> end.
Controller upgrade
Start ---> connect U disk (FAT32 format, with upgrade file) ---> main menu GG9 ---> confirm upgrade ---> F2
Update ---> automatic upgrade, restart the controller ---> end.
Start ---> connect U disk (FAT32 format, with upgrade file) ---> press upgrade button and restart the controller
---> F2 Update ---> automatic upgrade, restart the controller ---> end.
Special setting after turn on the controller
Operation
Setting
Instruction
GG1
Check controller ID
Display controller ID
GG2
Revise time
Display or revise controller time
GG3
Format
Delete all programs in local disk
ParaInitial
(parameters initialization)
All parameters become controller factory default, if become
machine supplier parameter settings, press “Parameter” – “High” –
L1 back to default setting
SetInitial
(settings initialization)
All settings become controller factory default, such as “speed
limitation”, “kerf” and other settings in auto and manual mode.
Chinese/English
Chinese/English
New Code
Set power-on password
GG5
User No.:
Code:
Input machine supplier ID and verification code, we offer that ID
for encryption.
GG6
Upgrade Word?
Upgrade word stock and power-on background picture
GG7
Version Info
Check controller software version
GG8
Is Change Logo Name
Connect U disk with company name
GG9
Upgrade?
Upgrade controller software
G90
Log in
There is a 6-digit number
