BR 800 13
5.3 Fitting the Harness
N Position the waist belt (2) against the backplate.
N Insert and tighten down the screws (3) firmly.
N Position the harness straps (5) against the backplate.
N Insert and tighten down the screws (4) firmly.
N Rotate the lower sliding adjusters of the harness
straps (1 and 5) through 90° and push them in
through the openings in the backplate.
N Push the upper sliding adjusters of the harness straps
(1 and 5) through the openings in the backplate.
5.4 Removing the Backplate Extension
N Preparations, @ 3.1.
N Remove the upper sliding adjusters, @ 5.2.
N Take out the screws (7).
N Remove the backplate (6).
N Engage the upper sliding adjusters, @ 5.3.
5.5 Fitting the Backplate Extension
N Preparations, @ 3.1.
N Disengage the upper sliding adjusters, @ 5.2.
N Place the backplate (6) in position.
N Insert and tighten down the screws (7) firmly.
N Engage the upper sliding adjusters, @ 5.3.
